Description
Insize Digital Outside Micrometer
The Insize 3109-200A Digital Outside Micrometer is engineered for measuring external dimensions from 175 to 200 mm with high accuracy. It features a 0.001 mm (0.00005") resolution and ±4 µm accuracy. The carbide measuring faces provide outstanding wear resistance, and the friction thimble ensures uniform measuring pressure. An automatic power-off system helps extend battery life. The micrometer comes with a spherical anvil for tube wall thickness measurements and a setting standard for calibration.
Specifications :
-
Part No: 3109-200A
-
Range: 175–200 mm / 7–8"
-
Resolution: 0.001 mm / 0.00005"
-
Accuracy: ±4 µm
-
L: 207 mm
-
a: 20 mm
-
b: 117 mm
-
Measuring Faces: Carbide
-
Functions: On/off, set, mm/inch, ABS/INC
-
Power Supply: Battery powered, automatic power off
-
Included Accessories: Spherical anvil, setting standard
-
Data Output: None
With precision engineering and durable carbide contact surfaces, the INSIZE 3109-200A is a dependable tool for precise measurement of large external diameters.
