Description
Insize Digital Outside Micrometer
The Insize 3109-250A Digital Outside Micrometer measures external dimensions in the 225 to 250 mm range with a resolution of 0.001 mm (0.00005") and ±4 µm accuracy. Its carbide measuring faces ensure excellent wear resistance, and the friction thimble provides consistent measurement force. The micrometer includes automatic power-off to extend battery life, a spherical anvil for measuring tube wall thickness, and a setting standard for calibration.
Specifications :
-
Part No: 3109-250A
-
Range: 225–250 mm / 9–10"
-
Resolution: 0.001 mm / 0.00005"
-
Accuracy: ±4 µm
-
L: 260 mm
-
a: 20 mm
-
b: 143 mm
-
Measuring Faces: Carbide
-
Functions: On/off, set, mm/inch, ABS/INC
-
Power Supply: Battery powered, automatic power off
-
Included Accessories: Spherical anvil, setting standard
-
Data Output: None
Engineered for industrial accuracy and durability, the INSIZE 3109-250A is ideal for large-diameter external measurements.
