Description
Insize GO Thread Ring Gauge
The INSIZE 4121-5D2 GO Thread Ring Gauge is a precision inspection tool designed to verify the external thread dimensions of 5/16-24UNF-2A fasteners. Manufactured to ANSI/ASME B1.2 standards, this gauge ensures that threaded components meet specified tolerances, making it essential for quality control in manufacturing and assembly processes.
Specifications :
-
Part No: 4121-5D2
-
Thread Size: 5/16-24 UNF
-
Thread Class: 2A
-
Gauge Type: GO (Plus)
-
Standard Compliance: ANSI/ASME B1.2
-
Design: Solid ring gauge
-
Finish: Uncoated
-
Included Certification: Manufacturer's inspection certificate
-
Country of Origin: China
Well-designed and durable, the INSIZE 4121-5D2 GO Thread Ring Gauge ensures precise measurements for verifying the dimensions of external threads. Its compliance with ANSI/ASME B1.2 standards and solid ring design provides reliable performance in manufacturing and assembly environments. This tool is ideal for ensuring that fasteners meet required tolerances, making it a critical instrument for quality control professionals.
