Description
Insize Dial Snap Gauge
The Insize 2185-25W Dial Snap Gauge is a precision measuring instrument designed for quick and accurate Go/No-Go assessments of external diameters, particularly in high-volume production settings. Its robust construction and ergonomic design make it ideal for inspecting shafts, cylinders, and similar components with efficiency and reliability.
Specifications :
-
Part No: 2185-25W
-
Measuring Range: 0–25 mm
-
Anvil Retracting Stroke: 3 mm
-
Measuring Force: 6–9 N
-
Measuring Faces: Carbide-tipped for enhanced durability
-
Anvil Design: Chamfered front edges for easy workpiece insertion
- Frame Dimensions:
- Optional Indicators:
- Dial Indicator (Code: 2308-10FA)
- Digital Indicator (Code: 2103-10F)
- Digital Indicator (Code: 2104-10F)
Well designed, durable, and high-precision tools suitable for measuring external diameters of shafts and cylindrical components. The Insize Dial Snap Gauge is a reliable and efficient instrument for high-volume production environments, offering quick and accurate Go/No-Go checks with ease and durability.
